JJ Sinclair

Overview
JJ Sinclair is a well known glider pilot in the western USA. He flies a Genesis II sailplane. He makes some unique and useful soaring products which are available below.


JJ Sinclair in his Genesis II sailplane


How to Order
To order a product, click on the button next to the product.
When you are ready to complete your order, click on the button.
Click on the small images to view larger versions.

Part # Description Photo
(Click on images below to view large versions)

Price

Lead-time
JJ-Wing-Tie-Down-Kit

JJ Wing Tie-Down Kit
The JJ Wing Tie Down Kit is a simple, yet effective solution for anchoring your wings to the ground. It is especially helpful if your glider does not have tie-down fittings. As you can see in the photo at right, the system uses a padded aluminum wing saddle and tie-down ratchet straps with 2 hooks. The wing saddle fits over the trailing edge of the wing and the straps run around the leading edge of the wing and down to the hooks for attachment to an anchor. The system is designed to be small and lightweight - so you can take it along with you on your cross-country soaring adventures.

Note: The saddle must be used on a wing surface with a fixed trailing edge - not on a moveable control surface.

This version is for use mainly with single-seat gliders. For large sailplanes and motorgliders - see the heavy-duty version below.

Anchors are not included.

Important:

  • Strong Recommendation: A wing stand under each wing is highly recommended in windy or gusty conditions in which the wind exceeds ~25 mph. Home Depot sells a solid, variable height stand for about $15, or ladder with pad on top makes a solid inexpensive wing stand.

Included:

  • 2 padded aluminum wing saddles
  • 2 tie-down ratchet straps with 2 hooks each, Width: 1 inch, Length: 15 feet, Breaking strength: 1500 Lb, Working Load Limit: 500 Lb.

Not Included:

  • Anchors or spikes or stakes for securing the system to the ground. For that you may want to consider the CLAW system.

Dimensions:

  • Width: 7.8 inches (20 cm)
  • Length: 7.5 inches (19 cm)
  • Weight of complete kit (including 2 wing saddles and straps and hooks): 2.6 pounds (1.18 Kg)

$125 In Stock
JJ-Wing-Tie-Down-Kit-HD

JJ Wing Tie-Down Kit - Heavy Duty
The JJ Wing Tie Down Kit is a simple, yet effective solution for anchoring your wings to the ground. This heavy-duty version is designed for use with large sailplanes and motorgliders. It is especially helpful if your glider does not have tie-down fittings. As you can see in the photo at right, the system uses a padded aluminum wing saddle and tie-down ratchet straps with 2 hooks. The wing saddle fits over the trailing edge of the wing and the straps run around the leading edge of the wing and down to the hooks for attachment to an anchor. The system is designed to be small and lightweight - so you can take it along with you on your cross-country soaring adventures.

Note: The saddle must be used on a wing surface with a fixed trailing edge - not on a moveable control surface.

Important:

  • Strong Recommendation: A wing stand under each wing is highly recommended in windy or gusty conditions in which the wind exceeds ~25 mph. Home Depot sells a solid, variable height stand for about $15, or ladder with pad on top makes a solid inexpensive wing stand.

Anchors are not included.

Included:

  • 2 padded aluminum wing saddles
  • 2 tie-down ratchet straps with 2 hooks each. Width: 2", Length: 10 feet, Load Capacity: 4000 pounds, Working Load Limit: 1333 pounds

Not Included:

  • Anchors or spikes or stakes for securing the system to the ground. For that you may want to consider the CLAW system.

Dimensions:

  • Width: 12 inches (30.5 cm)
  • Length: 12 inches (30.5 cm)
  • Weight of 2 wing saddles: 3.7 Lbs
  • Weight of 2 tie-down ratchet straps: 4.75 Lbs
  • Weight of complete kit (including 2 wing saddles and straps and hooks): 8.45 pounds (3.83 Kg)

$163 In Stock
JJ-Wing-Runner

JJ Wing Runner
The JJ Wing Runner is clever, compact and lightweight wing wheel that can be used to assist with take-off when a human wing runner is not available. It would be very handy in the event of a off-airport landing and subsequent retrieve aerotow. It will keep your aileron from grinding on the pavement as you use full side-stick to lift the low wing (down aileron on the low wing). It lifts the down wing about 6 inches (15 cm) above the pavement - keeping the aileron up off the ground. The wheel and wheel mounting brackets fit neatly inside the wing saddle for storage inside your glider.

Included:

  • 1 padded aluminum wing saddle
  • 1 wheel with mounting brackets
  • 36" roll of duct tape - for securing the saddle to the wing
  • Printed assembly and use Instructions

Dimensions:

  • Width: 7.5 inches (19 cm)
  • Length: 7.5 inches (19 cm)
  • Wheel diameter: 5.1 inches (13 cm)
  • Weight of complete kit: 1.2 pounds (0.54 Kg)

Instructions



$100 In Stock
