Airpath Compasses

Overview
Airpath compasses are installed in most new airplanes.  They are a good value as well as extremely reliable and accurate.

How to Order
To order a product, click on the
button next to the product.
When you are ready to complete your order, click on the
button.
Click on the small images to view larger versions.

Part # Description Photo
Click on image to view larger version

Price

Lead-time

AP-C-2300 Airpath Compass, Instrument Panel Mount
All compasses in the C-2300 series meet FAA TSO-C7c requirements. Each has been specifically designed for panel-mount installation on four holes (0.170 Dia.) equally spaced about a 2 5/8 mounting circle.  Each model is provided with a deviation card, deviation card window, and a deviation card-holder easily mounted near the compass for easy reference. Fits in a 57 mm (2 1/4") instrument hole.  Mounting screws included.

 - Note: This unit is compensated for use anywhere in the northern hemisphere.  Versions for the southern hemisphere are available upon request.  The price is $15 extra to cover shipment of the custom product to my office. I don't stock versions for the southern hemisphere. The lead-time is 4 to 6 weeks for southern hemisphere versions.

$195 In Stock
AP-C-2400-P Airpath Compass, Pedestal Mount
For mounting on the top of the instrument panel.
All compasses in the C-2400 series meet FAA TSO-C7c requirements. Each has been specifically designed for installation either for streamline-type bracket housing or a pedestal-type housing. Each model is provided with mounting hardware, deviation card, deviation card window and either an attached cardholder, deviation plate, or standard unattached cardholder depending on the application.  Mounting screws included.

Dimensions
Diameter of main body: 2.40 inches (61 mm)
Length from front face to back of unit: 3.38 inches (86 mm)
Height at highest point (near back): 2.76 inches (70 mm)
Height at front (it slopes forward slightly - perfect for panels which slope down toward the front): 3.50 inches (66.5 mm)
Width of mounting base: 2.81 inches (71.5 mm)
Length of Mounting Base: 2.81 inches (71.5 mm)

 - Note: This unit is compensated for use anywhere in the northern hemisphere.  Versions for the southern hemisphere are available upon request.  The price is $15 extra to cover shipment of the custom product to my office. I don't stock versions for the southern hemisphere. The lead-time is 4 to 6 weeks for southern hemisphere versions.

$235 In Stock
